TouchTunes Angelina

Three independent LED zones pulse to the track's texture. Twenty-four inches of wall. The light washes the surrounding wall, not just the cabinet face.

Overview

The TouchTunes Angelina is a wall-mount internet jukebox that occupies just 24 inches of wall space while projecting a floating, frameless appearance. Onboard algorithms drive music-synchronized LED lighting across three configurable zones — light show, brand bar, and sound visualizer — and a built-in HD camera lets patrons launch a photo booth session from the same touchscreen used to queue music. Snap-in, no-wire component-to-component design keeps service time short and parts inventory low.

Key Features

Three-Zone Music-Synchronized LED Lighting

The Angelina's lighting system runs across three independently configurable zones. The Light Show washes the surrounding wall in any color, static or pulsating, shifting with the playing track. The Brand Bar is a separate horizontal strip of light that can match the light show or be locked to a different color — useful for operators who want consistent brand presence regardless of song. The Sound Visualizer reads the music's dynamics and renders one of three selectable patterns (Firefly, Waves, or Bubbles) in a chosen color palette, flowing in real time to the audio. Each zone is configured separately, so the visual output changes song to song and is visible from across the room.

Built-In Photo Booth via HD Camera

A single button press from the touchscreen switches the Angelina into a full photo booth mode. The HD camera is integrated into the cabinet — no external kiosk, no secondary hardware required. The same unit that plays music delivers the photo experience.

Snap-In, No-Wire Component Design

Internal components connect directly to one another without loose wiring harnesses. Parts snap into position, so a technician replaces a module by removing it and pressing in the new one. This approach reduces the number of connectors that can fail and shortens on-site service visits.

Dual ICEpower Amplifiers with Three-Zone Audio

Two 2-channel ICEpower amplifiers with integrated power supplies drive three independent audio zones: two internally powered and one externally powered. Each zone has its own independent input volume control. Over-current and thermal shutdown protection is built in, and a microphone input with talk-over switch is included (Microphone DI box required). A balanced AUX input provides better noise immunity for line-level sources (Line-In DI box required).

64-Bit Hardware Platform with Fanless Cooling

The Angelina runs on a 64-bit CPU paired with a 500 GB SATA hard drive for local music storage. Fanless, passive cooling eliminates a moving-part failure point and keeps operating noise low. Connectivity includes wired and wireless broadband, DHCP and Static IP support, and 4G/LTE wireless capability. Two ICT bill acceptors handle cash payment.

How It Plays

A patron selects a track from the TouchTunes catalog on the touchscreen and the three LED zones — light show, brand bar, and sound visualizer — shift into the song's pattern within moments of playback starting, washing the wall around the cabinet in color visible from across the room. From the same screen, a button press switches the unit into photo booth mode, where the integrated HD camera captures and delivers the session without any secondary hardware in view.

Specifications

Why Operators Love It

Single-Person Wall Installation

At 24 inches wide and 88 lbs, the Angelina is designed for one-person installation on a standard wall — no floor footprint consumed, no heavy rigging required. The slim 9.7-inch depth keeps it flush against the wall without protruding into patron traffic.

Fanless Passive Cooling Removes a Common Failure Point

Fan motors are among the most frequent service calls on jukebox hardware. The Angelina's passive cooling system has no fan to replace, clean, or listen for — and the absence of a moving-part cooling loop also keeps the cabinet quieter in low-ambient-noise environments.

Over-Current and Thermal Shutdown Protection

Both ICEpower amplifiers include integrated over-current and thermal shutdown protection. If either condition is reached, the amplifier shuts down before damage occurs — protecting the hardware without requiring operator intervention.

4G/LTE Fallback Connectivity

The Angelina supports wired broadband, Wi-Fi, and 4G/LTE wireless, along with both DHCP and Static IP configurations. The unit can go online in venues where hardwired ethernet is impractical, and can fall back to cellular if the local network goes down.

Frequently Asked Questions

How much wall space does the TouchTunes Angelina require?

The Angelina mounts to a wall and occupies 24 inches of horizontal wall space, with a depth of 9.7 inches. It consumes no floor footprint. The full assembled dimensions are 24 in W x 9.7 in D x 31 in H, and the unit weighs 88 lbs.

Does the TouchTunes Angelina include a photo booth function?

Yes. The Angelina has an integrated HD camera and a dedicated photo booth mode accessible directly from the touchscreen. Switching between jukebox and photo booth requires only a button press — no separate hardware or kiosk is involved.

How is the TouchTunes Angelina serviced in the field?

Internal components use a no-wire, component-to-component architecture with snap-in part replacement. A technician removes the failed module and presses in the replacement — there are no loose wiring harnesses to route or reconnect. TouchTunes designed this approach to reduce parts inventory needs and shorten on-site service time.

How many LED lighting zones does the Angelina have, and are they configurable?

The Angelina has three independently configurable LED zones: the Light Show (wall wash, any color, static or pulsating), the Brand Bar (a separate horizontal strip lockable to a chosen color), and the Sound Visualizer (pattern and color palette selectable from Firefly, Waves, or Bubbles). Each zone is set independently, so they can match one another or run separate configurations simultaneously.

Ideal Placement

The Angelina's wall-mount form factor suits venues where floor space is at a premium: bars and tavern game rooms, pizzerias, bowling center lobbies, restaurant waiting areas, and hotel game rooms. At 24 inches wide and 9.7 inches deep, it fits into wall alcoves and narrow corridors that floor-standing jukeboxes cannot occupy. Breweries and national chain locations looking to add both music and a photo experience without a second dedicated kiosk will find the dual-function cabinet a practical fit.
